If you're between sizes, we usually recommend going smaller. It's easier to tweak the fit with a longer stem or more seat post, while a bigger frame gives you less room to adjust.

Weight varies by build and fork type. Based on a medium frame size:

• Apex XPLR AXS build: 13.9 kg (carbon forks) / 14.6 kg (RockShox Rudy Ultimate)
• Apex XPLR build: 13.8 kg (carbon forks) / 14.5 kg (RockShox Rudy Ultimate)
• SPORTFIT: 13.8 kg (carbon forks) / 14.5 kg (RockShox Rudy Ultimate)

Frame only (medium): 2.0 kg in a raw finish.

Like all Ribble bikes, the ALLGRIT E AL SPORTFIT comes with a lifetime frame and fork warranty for the original owner. This covers any manufacturing defects in materials or workmanship. All other components, including third-party suspension forks, are covered by the standard manufacturer’s warranty.

Yes. The ALLGRIT E AL SPORTFIT is available with the optional RockShox Rudy suspension fork. This upgrade enhances comfort and control on rougher gravel trails, allowing you to stay fast and confident when the terrain becomes technical.

Range depends on rider weight, terrain, tyre pressure, and temperature. As a guide, a 90 kg rider on mixed routes can expect up to 90 km on a full charge. Add the optional eX1 range extender and this increases by up to 60 km.

Yes. The ALLGRIT E AL SPORTFIT is pedal-assisted, so it always requires rider input. Stop pedalling and it coasts to a stop. Just like a regular bike.

Absolutely. The motor only provides assistance when you pedal. You’re always in full control of speed and handling.

No. You don’t need a licence, tax or insurance to ride pedal-assisted electric bikes in the UK. That said, we always recommend having some form of bike insurance.

Yes, the ALLGRIT E AL SPORTFIT is eligible for Cycle to Work.

The Duo handlebar remote allows you to adjust assistance levels with a single press, providing effortless and intuitive control at your fingertips. Assistance levels are shown as follows:

• White: off
• Green: minimum
• Orange: medium
• Purple: maximum
• Cyan: smart assist via app

The ALLGRIT E AL’s X30 control unit shows battery charge with seven LEDs.

• Fully lit = 94–100%
• Fewer lights = lower charge
• Slow blinking = 0–10%
• Fast blinking = critically low

Just plug into any standard socket using the supplied charger. The optional range extender can also be used to charge the main battery on the go.

Yes, you can test ride the ALLGRIT E AL SPORTFIT at our Clitheroe showroom or during UK demo events. Contact the showroom in advance to reserve your test bike.

Yes. The ALLGRIT E AL SPORTFIT’s electrical components are IP54 rated for splash protection but should not be jet washed or fully immersed. Use a waterproof cover when transporting in wet conditions.

Yes. A MAHLE-certified technician can remove the battery by taking off the press-fit bottom bracket via the bottom bracket shell.

The ALLGRIT E AL SPORTFIT's iX2 battery is designed to handle around 500 full charge cycles with minimal degradation, provided it is stored and maintained correctly.

Yes. The ALLGRIT E AL features integrated cable routing for a clean look and protection from the elements.

The ALLGRIT E AL SPORTFIT comes with 40mm tyres as standard and can take up to 50mm, or 45mm with mudguards. The front forks will also accept a 29 x 2.1" (700x53c) mountain bike tyre.

Yes, you can fit a rear pannier rack using an adaptor kit (sold separately) to boost carrying capacity by up to 15 kg.

No, it is not approved for use with child safety seats.

Yes. A removable mudguard bridge makes fitting mudguards easy (kit sold separately).

The frame uses a Mahle-specific press-fit PF46 bottom bracket with an integrated torque sensor.

It features a 1.5” integrated headset with R457B 52 x 42 x 7 mm 45° x 45° bearings.

The ALLGRIT E AL comes with a D-shaped alloy seat post (8mm setback), compatible with carbon or alloy saddle rails.

Two: one on the downtube and one on the seat tube, positioned to work with the Ribble seat tube-specific aero bottle cage.

The ALLGRIT E AL SPORTFIT has full frame mounts including rear rack, top tube, downtube, and carryall mounts on the forks.

Thru axle and bolt on: M12 x 1.5 mm x 123 mm (front) - bolt-on (rear).

Yes, the ALLGRIT E AL accepts 34.9 mm front derailleurs and 2x compact road chainsets (34/50T), though it comes standard with a 1x drivetrain.

It features a proprietary derailleur hanger designed specifically for the MAHLE e-system, ensuring perfect alignment.

The ALLGRIT E AL SPORTFIT supports a total system weight of 120 kg including rider, bike, and luggage.

The ALLGRIT E AL SPORTFIT is designed for the latest flat-mount disc brakes.

Yes, the bike comes with a set of flat platform pedals for general use.
